标准光模块
1.25Gbps RS LC Transceiver (40Km)
Description
1.25Gbps RS LC Transceiver (40Km)
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● 2-Fiber RS LC Transceiver
● 1310 DFB transmitter,PIN photo-detector Receiver
● Distance up to 40 km
● Single 3.3V Power Supply
● 0 to 70℃ Operating Temperature
● -40 to 85℃ Operating Temperature
APPLICATIONS
● WDM Gigabit Ethernet Links
● SONET/SDH Equipment Interconnect
● Fiber Channel Links
Ordering Information
|
P/No. |
Package |
Bit Rate (Gb/s) |
Dist. (km) |
Wavelength (nm) |
TX Power (dBm) |
RX Sens (dBm) |
Volt. (V) |
Temp. (℃) |
DDM |
|
FT-95-RS-1312-40D |
LC |
1.25 |
40 |
1310 |
-3 to +2 |
-23 |
3.3 |
0 ~70 |
YES |
|
FT-95-RS-1312-40DI |
LC |
1.25 |
40 |
1310 |
-3 to +2 |
-23 |
3.3 |
-40 ~85 |
YES |
本产品为FT-95-系列，仅展示部分参数，如有需要，请联系大宝娱乐。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
