10Gbps MiniSFF LC Transceiver (300m)
Description
10Gbps MiniSFF LC Transceiver (300m)
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● 850 nm VCSEL Laser,PIN photo-detector Receiver
● 2-Fiber MiniSFF LC Transceiver
● Distance up to 300 m
● Single 3.3V Power Supply
● Operating case temperature:
FT-95-85RCxx1X-02D : 0℃~+70℃
FT-95-85RCxx1X-02DI : -40℃~+85℃
APPLICATIONS
● 10GBASE-LR/LW 10G Ethernet
本产品为FT-95系列，仅展示部分参数，如有需要，请联系大宝娱乐。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
