6.25Gbps MiniSFF CWDM Transceiver
Description
6.25Gbps MiniSFF CWDM Transceiver
FEATURES
● Surface mount I/O pins for high speed signal integrity
● All metal body, solder or screw mount options
● Industrial Temp range, vibration tolerant design
● 2-Fiber MiniSFF LC Transceiver
● 1270～1610nm CWDM Cooled DML transmitter , APD photo-detector
● Single 3.3V Power Supply
● Operating case temperature: -40 ℃to 85℃
APPLICATIONS
● CWDM optic fiber transmission system
Ordering Information
|
P/No. |
Temp. (℃) |
Wavelength (nm) |
Dist. (km) |
TX Power (dBm) |
RX Sens (dBm) |
Package |
Bit Rate (Gb/s) |
Volt. (V) |
|
FT-95-RS-C2762-DZ01 |
-40~85 |
1270 |
40 |
0 to +5 |
-24 |
LC |
6.25 |
3.3 |
|
FT-95-RS-C2962-DZ01 |
-40~85 |
1290 |
||||||
|
FT-95-RS-C3162-DZ01 |
-40~85 |
1310 |
||||||
|
FT-95-RS-C3362-DZ01 |
-40~85 |
1330 |
||||||
|
FT-95-RS-C3562-DZ01 |
-40~85 |
1350 |
||||||
|
FT-95-RS-C3762-DZ01 |
-40~85 |
1370 |
||||||
|
FT-95-RS-C3962-DZ01 |
-40~85 |
1390 |
10 |
|||||
|
FT-95-RS-C4162-DZ01 |
-40~85 |
1410 |
||||||
|
FT-95-RS-C4362-DZ01 |
-40~85 |
1430 |
||||||
|
FT-95-RS-C4562-DZ01 |
-40~85 |
1450 |
||||||
|
FT-95-RS-C4762-DZ01 |
-40~85 |
1470 |
||||||
|
FT-95-RS-C4962-DZ01 |
-40~85 |
1490 |
||||||
|
FT-95-RS-C5162-DZ01 |
-40~85 |
1510 |
||||||
|
FT-95-RS-C5362-DZ01 |
-40~85 |
1530 |
||||||
|
FT-95-RS-C5562-DZ01 |
-40~85 |
1550 |
||||||
|
FT-95-RS-C5762-DZ01 |
-40~85 |
1570 |
||||||
|
FT-95-RS-C5962-DZ01 |
-40~85 |
1590 |
||||||
|
FT-95-RS-C6162-DZ01 |
-40~85 |
1610 |
本产品为FT-95-系列，仅展示部分参数，如有需要，请联系大宝娱乐。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
