3.3V 2X5 2.5G SFF BIDI Single Mode Transceiver
Description
3.3V 2X5 2.5G SFF BIDI Single Mode Transceiver
FEATURES
● Single 3.3 Volt DC supply
● 2x5 SFF BIDI Package Outline
● SC connector
● Differential CML inputs and outputs
● Distance up to 20 km
● LVTTL Signal Detect output
● Operating case temperature: -40 ℃to 85℃
● Class 1 laser product complies with EN 60825-1
● RoHs Compliance
APPLICATIONS
● SDH STM-16 and SONET OC-48 system
● Switch to switch interface
● Other Optical Links
本产品为FTAF系列 ，仅展示部分参数 ，如有需要 ，请联系大宝娱乐。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
