0~100Mbps MINISFF LVTTL Single Mode Receiver (10Km)
FEATURES
¡ñ All metal body, solder or screw mount options
¡ñ MiniSFF FC Pigital Receiver
¡ñ DC~100M Data Rate
¡ñ Distance up to 10km
¡ñ LVTTL Outputs
¡ñ Single 3.3V Power Supply
¡ñ RoHs Compliance
¡ñ Operating case temperature:
Commercial: 0 ~ +70¡æ
Industrial: -40 ~ +85¡æ
APPLICATIONS
¡ñ Low Rate Bus transmission system
¡ñ Unbalanced Signal transparent transmission system
Ordering Information
P/No. |
Wavelength (nm) |
RX Sens (dBm) |
Package |
Bit Rate (Mb/s) |
Volt. (V) |
Temp. (¡æ) |
FT-95-RS-R13L4-10 |
1100~1620 |
-12 |
FCβÏË |
0~100 |
3.3 |
0 ~70 |
FT-95-RS-R13L4-10I |
1100~1620 |
-12 |
FCβÏË |
0~100 |
3.3 |
-40 ~85 |
NOTE : FT-95-RS-R13L4-10I
X=01, ¹âÏ˳¤¶È£º0.1m
X=02, ¹âÏ˳¤¶È£º0.2m
...
X=09, ¹âÏ˳¤¶È£º0.9m
X=10, ¹âÏ˳¤¶È£º1.0m
X=12, ¹âÏ˳¤¶È£º1.2m
X=15, ¹âÏ˳¤¶È£º1.5m
X=18, ¹âÏ˳¤¶È£º1.8m
X=20, ¹âÏ˳¤¶È£º2.0m
±¾²úƷΪFT-95-ϵÁУ¬½öչʾ²¿·Ö²ÎÊý£¬ÈçÓÐÐèÒª£¬ÇëÁªÏµ´ó±¦ÓéÀÖ¡£
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
