100G QSFP28 to 2x 50G QSFP28 Copper Breakout

100G QSFP28 to 2x 50G QSFP28 Copper Breakout

0.0/5 rating (0 votes)

Description

Features
●Compliant with SFF-8665
●Compliant with IEEE 802.3bj
●Up to 100Gb/s data rates
●Ultra low crosstalk for improved performance
●Low insertion loss
●Serial numbers printed on each end
●Tested in an end-to-end system
●RoHS compliant

Applications
●Low EMI radiation Switches, servers and routers
●Data Center networks
●Storage area networks
●High performance computing
●Telecommunication and wireless infrastructure
●Medical diagnostics and networking
●Test and measurement equipment

Product Description
F-tone Networks’s FT-77-CAB-ZQP/2ZQP-PxM provide robust connections for leading edge100Gb/s systems. Passive copper cables require no additional power to ensure quality connectivity.The100Gb/s passive copper cables are fully compliant with SFF-8436 specification and provide connectivity between devices using QSFP28 ports. F-tone Networks’s FT-77-CAB-ZQP/2ZQP-PxM fill the need for short, cost-effective connectivity in the data center. F-tone Networks’s high-quality solutions provide a power-efficient replacement for active power connectivity such as fiber optic cables for short distances. Optimizing systems to operate with F-tone Networks’s FT-77-CAB-ZQP/2ZQP-PxM significantly reduces power consumption and EMI emission.

26











Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
