40G QSFP+ TO 4X SFP+ Passive Copper Cable Assembly
Description
Features
●Fully compliant to the latest SFP+ & QSFP+ MSA
●Supports 40-Gigabit Ethernet standards
●Up to 10.3125 Gbps transfer rate per SFP+ channel
●30 AWG to 26 AWG cable sizes available
●100 ohm differential impedance system
●All-metal housing for superior EMI performance
●Precision process control for minimization of pair-to-pair skew
●AC coupling of PECL signals
●EEPROM for cable signature & system communications
●Low cross-talk
●RoHS compliant
Applications
●InfiniBand SDR, DDR,QDR
●40G Ethernet transmission
●Fiber Channel
●Rack-to-Rack, Shelf-to-Shelf Interconnect
●Networking
●Hubs, switches, routers, servers
●Data center interconnect
●High Performance Computing application
Product Description
interconnect solution for merging 40G QSFP and 10G SFP+ enabled host adapters, switches and servers. For typical applications, users can install this splitter cable between an available QSFP port on their 40-Gigabit/s rated switch and feed up to four upstream 10GbE-SFP+ enabled switches. Each QSFP-SFP+ splitter cable features a single QSFP connector (SFF-8436) rated for 40-Gb/s on one end and (4) SFP+ connectors (SFF-8431), each rated for 10-Gb/s, on the other. 10GSFP is the manufacturer of QSFP to 4 SFP+ Splitter Cables that designs and sources every subassembly in-house guaranteeing complete control over product performance, quality and consistency. Examples include our widely respected board-as-connector platform which is direct-welded to the wire and encased in a robust Zinc Nickel back shell for superior crosstalk and EMI performance. Cable available in 0.5M (1.7ft), 1m (3.3ft), 2m (6.6ft), 3m (9.8ft) & 5m (16.4ft) lengths to accommodate your installation requirements.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
