Features
●Compliant with SFF-8436
●Fully compatible with IEEE802.3ba and Infiniband
●QDR specifications 40 Gb/s total bandwidth
●4 independent duplex channels operating at 10Gbps, also support for 2.5Gbps, 5Gbps data rates
●Low power <1.5W, low latency analog circuitry
●Uses advanced analog signal processing technology
●All-metal housing for superior EMI performance
●BER better than 10-12
●AC coupling of PECL signals
●Ultra low crosstalk for improved performance
●EEPROM for cable signature & system communications
●30 AWG to 26 AWG cable sizes available
●Tested in an end-to-end system
●RoHS compliant
Applications
●Data Servers、Routers、Switches
●Networked storage systems
●Data Center networking
●InfiniBand Trade Association (IBTA)
●IEEE-802.3ba
●40Gigabit Ethernet ( 40G BASE–CR4)
Product Description
F-tone Networks active copper cables are 40Gb/s cables assembly. The cables are compliant with InfiniBand Architecture, SFF-8436 specifications and provide connectivity between devices using QSFP ports.
The F-tone Networks QSFP cable is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s per direction, providing an aggregated rate of 40Gb/s. The cables use state of-the-art signal processing technology to fill the expanding need for cost effective data center interconnects that cannot be served with passive copper solutions. F-tone Networks unique low power cable solutions consume 50-75% less power than optical interconnects. Optimizing systems to operate with F-tone Networks’s active copper cables significantly reduce power consumption and EMI emission, eliminating the use of EDC hosts. Rigorous cable production testing ensures best out-of-the-box installation experience, performance and durability.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
