J599A8（ARINC801）系列光纤连接器

0.0/5 rating (0 votes)

Description

产品简介
● 接口尺寸切合GJB599A(MIL-DTL-38999) Ⅲ，性能切合ARINC801标准
● 适用于航空、电子、舰船等系统，用于多路光通信
● 接纳标准1.25mm陶瓷插针，对接精度高
● 陶瓷套管封装阵列，可整体拆卸更换，便于使用维护
● 接触件装置取卸工具M81969/14-03，操作便当

主要技术指标
机械性能
● 机械寿命：500次插拔循环
● 攻击：加速980m/s²
● 振动：10～2000Hz，加速度196m/s ²
● 抗拉力：≥68N（2mm接触件跳线）
情况性能
● 温度规模：-55℃～+85℃
● 盐雾： K类、W类：1000h F类：48h
● 盐雾：气密封性（适于气密转接插座）：气体泄漏率≤1×10-9Pa.m³/s，内外压差为1大气压
光学性能
● 插入损耗：≤0.6dB

B 36 B 36 B 36 B 36 B 36 B 36 B 36 B 36 B 36 B 36

注：本产品有全国产化型号可选
Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
