10.3125Gb/s CSFP BIDI Transceiver
Description
10.3125Gb/s CSFP BIDI Transceiver
Product Features
● Two Bi-Directional transceivers in one SFP package
● Up to 10.3125Gb/s data links
● Duplex LC connector
● Hot-pluggable SFP footprint
● Uncooled DFB laser transmitter
● RoHS compliant and Lead Free
● Up to 10Km on 9/125um SMF
● Metal enclosure for lower EMI
● Single +3.3V power supply
● Compliant with CSFP MSA 2.0 (Option 2)
● Commercial operating temperature optional
Regulatory Compliance
● ESD to the Electrical PINs: compatible with MIL-STD-883 Method 3015
● ESD to the Single LC Receptacle: compatible with IEC 61000-4-2
● Immunity compatible with IEC 61000-4-3
● EMI compatible with FCC Part 15 Class B EN55022 Class B (CISPR 22B) VCCI Class B
● Laser Eye Safety compatible with FDA 21CFR 1040.10 and 1040.11 EN60950, EN (IEC) 60825-1,2
● RoHS compliant with RoHS 2 (2011/65/EU)
Applications
● 10GBASE-LR/LW
● 10G Fibre Channel
Product Selection
|
Part Number |
Wavelength |
Operating Case temperature |
|
CSFP-10G-10A |
Tx-1270 / Rx-1330 |
Commercial |
|
CSFP-10G-10B |
Tx-1330 / Rx-1270 |
Commercial |
|
CSFP-10G-10AI |
Tx-1270 / Rx-1330 |
Industrial |
|
CSFP-10G-10BI |
Tx-1330 / Rx-1270 |
Industrial |
注：本产品有全国产化型号可选
本产品为CSFP系列光�？�，仅展示部分参数，如有需要，请联系大宝娱乐 。
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
