Key features and benefits
¡ñ Easy : Comfortable Push-Pull latch design - Keying, color identification and Blind Mating features
¡ñ Safe & Waterproof : 2,000 cycles - IP68 in mated and unmated conditions
¡ñ Sterilization : Can withstand steam autoclave sterilization (up to 200 cycles) Aesthetic : Ergonomic, Lightweight and Sleek
¡ñ Compliant with : UL 1977 and IEC 61984 facilitating your equipment's compliance with IEC 60601-1

Description
The waterproof and extreme high temperature resistance characteristics of the JMX series makes it ideal for Medical, Instrumentation and Measurement applications. However, the plastic Push-Pull connectors can also be used in a diversity of other Industrial applications requiring a lightweight, yet durable harsh environment interconnect solution.
The JMX plastic Push-Pull connector series guarantees a reliable and secure connection with only two fingers. Connectors are available in 6 keys and 9 color identifying codes to avoid situations of incorrect mating.
Capable of over 2,000 mating cycles, the JMX connector series is also able to withstand steam autoclave sterilization per IEC 60601-1 (up to 200 cycles). In addition, it will protect your equipment from fluid ingress due to its IP68 attributes in mated and unmated conditions
The JMX Plastic Push-Pull connector is aesthetically and visually appealing to complement and blend with medical equipment designs. The curves of the coupling ring provides exceptional tactile comfort and an easy to handle grip design so that fingers will fit instinctively.

Technical Data
¡ñ Crimp or solder termination
¡ñ Operating temperature:
¡ñ Receptacle: -20°C +100°C
¡ñ Plug: -40°C +125°C
¡ñ Short term (autoclaving): Resistance up to +134°C
¡ñ Will withstand steam autoclave sterilization (Pre-vacuum & gravity displacement process) : 200 cycles
¡ñ IP68 (Mated and unmated conditions)
¡ñ 2000 mating cycles
¡ñ UL94 V-0
¡ñ RoHS and REACH compliant
¡ñ Push-Pull locking system

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
