HDMI Active Optical Cables Multimode Fiber Optic HDMI Extender

Description
The F-tone Networks HDMI Cable is a kind of Active Optical Cable (AOC) used to extend the transmission distance between HDMI Source and Sink devices. The transmission distance can be up to 100m (330ft) through a hybrid cable consisting of optical fibers and copper wires. The high-speed TMDS signals are transmitted through the optical multimode fibers, while the low frequency DDC and control signals are transmitted through the copper wires.
At the ends of the hybrid cable are a transmitter with a type A plug connected to the source devices and a receiver with a type A plug connected to the sink devices. Inside the transmitter, the electrical TMDS signals are converted into optical signals by the VCSEL array; while in the receiver, the optical signals are converted back into electrical TMDS signals by the photodiode array.
The optical sub-assemblies inside the transmitter and the receiver are produced by hybrid integration technology. Semiconductor process and passive aligned optical coupling make the product cost effective. The resulting compact dimensions can meet the specifications of HDMI type A plug.
It is feasible to connect any HDMI devices such as Blu-ray, DVR, projector, video games, computers and mobile to enjoy the high quality display.

Features
¡ñ Extend HDMI up to 100m over fiber optics(MMF)
¡ñ Compliant to link with all HDMI A-type connector
¡ñ Compliant with HDMI 1.4a version and category 2(340MHz clock frequency) specifications
¡ñ 850nm VCSEL transmitter, PIN photo-detector receiver
¡ñ Support 4k/3D/1080p/1080i/720p format
¡ñ Support DHCP/EDID/CEC/DDC/Audio
¡ñ Data rate:10.2Gbps(3.4Gbps per channel)
¡ñ Plug and play, no software to be installed
¡ñ Longer, thinner cable without EMI/RFI emissions
¡ñ Integrated USB connector draws power from the display
¡ñ Low power consumption
¡ñ Operating case temperature:
      Standard : 0 to +70°C
      Industrial : -40 to +85°C
¡ñ All-metal housing for superior EMI performance
¡ñ RoHS compliant (lead free)

Applications
¡ñ Blu-ray, DVR, projector
¡ñ Video Games
¡ñ Computers and mobile to Full HD display

Ordering information

×¢£º±¾²úÆ·ÓÐÈ«¹ú²ú»¯ÐͺſÉÑ¡
±¾²úÆ·½öչʾ²¿·Ö²ÎÊý
£¬ÈçÓÐÐèÒª
£¬ÇëÁªÏµ´ó±¦ÓéÀÖ¡£

Important Notice

Performance figures,data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone before they become applicable to any particular order or contract. In accordance with the F-tone policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone or others. Further details are available from any F-tone sales representative.
