Part Number£ºFT-45-TOSA-1XX0-2-SM

Product Description: The Pluggable TO56 CWDM series laser diodes are 1.27μm~1.61μm Multiple Quantum Well (MQW) structured distributed-feedback(DFB) laser modules. These laser diodes are built in a pluggable TO56 package with monitoring PIN-PD for fiberoptic communication systems. These modules are ideally suitable for 2.5Gbps transmission applications. The products are Telcordia GR-468 qualified, and in compliance with RoHS requirement.

Applications:
¨€ Telecommunication transceivers
¨€ Datacom transceivers
¨€ Fiberoptic sensors

Features:
¨€ CWDM laser diode module
¨€ Signal rate up to 10/25Gb/s
¨€ LC receptacle TOSA package
¨€ High output power£¨>2mW)
Reliability: Telcordia GR-468. RoHS

ÊÂÇéζȣ¨¶àÖÖζȼ¶±ð¿ÉÑ
¡£©:
ÉÌÓü¶£º0~+7¶È
À©Õ¹¼¶£º-10~+80¶È
¹¤Òµ¼¶£º-40~+85¶È
¾üÆ·¼¶£º-55~+85¶È

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
