2LC-2LC-4590-XX光纤跳线
Description
光纤跳线是指光纤线缆两端都有光纤运动连接器，用来连接设备到光纤布线链路，一般用在光端机和终端盒之间的连接，仅一端有光纤运动连接器的称为尾纤�？商峁┑ツ�，多模和OM3光纤跳线；凭据差别的型号与用途可分为LC、FC、SC、ST、D4、DIN、MU、MTRJ、MPO/MTP、E2000等种种型式；按连接器的研磨端面可分为PC（UPC）和APC；按光纤芯数分另有单芯、双芯之分。
应用:
● 光纤通信系统
● 光纤接入网
● 光纤数据传输
● 光纤CATV
● 局域网 (LAN)
● 测试设备
产品特性:
● PC,UPC, APC研磨计划
● 高可靠性与稳定性
● 高回波损耗，低插入损耗
● 插芯端面电子检测
● 良好的交换性
● 单�；蚨嗄９庀巳窝�
注：本产品有全国产化型号可选
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
