Features£º
¡ñ Data rates up to 2.5 Gbps.
¡ñ Single +3.3V Power Supply.
¡ñ GaAs PIN Detector and TIA inside.
¡ñ -40¡æ to 85¡æ Operation.
¡ñ High Sensitivity.
Applications£º
¡ñ Digital Optical Communication.
¡ñ Optical LAN.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
